Midas Heritage HD96-24-CC-IP
Start 360°
Live Digital Console Control Centre
- 144 Input channels
- 120 Flexi mix busses
- Sample rate: 96 kHz
- 21" Full HD multi touch screen
- 41 Full colour LCD info displays
- 28 Motor faders: 100 mm
- Channel AI
- Expansion slots: Dante
- Madi and USB interface support
- Weight: 24 kg
- Optional stageboxes: DL 231, DL151, DL152, DL153, DL154, DL155, DL251
available since
April 2022
Item number
543151
sales unit
1 piece(s)
User Interface
Physical/remote
Number of faders
28
DSP Input channels
144
Mic Preamp
8
Physical outputs
8
Digital stagebox connection
AES50
Hotspot
No
Multitrack Record
Yes
integratated Player/Rec via USB/SD
No
19" Rackmount
No
DSP Output Channels
120
Busses
120
Mono-Line Input
8
Stereo-Line Input
0
Ethernet
Ethernet
Soundcard interface
No
Recorder Format
No
Scribble Strips
1
RTA
No
FX Processor
96
Delay Input
1
Delay Output
1
Matrix
120
DCA/VCA Gruppen
24
Midi Connector
No
Sample rate
96 kHz
Separate Personal Monitor system
No
Expansion Card slots
2
Digital ADAT
No
Digital SPDIF
No
Digital AES3/ASESEB
Yes
Digital MADI
Yes
Digital Dante
Yes
110V capable
1
Case
Optional
Weight
24 kg
